Description
The TSF010 is an unmanaged Ethernet switch featuring a flat design and integrated DIN rail mounting for plug-and-play deployment in industrial cabinet applications. This Ethernet switch is compact and lightweight, measuring 113 x 28 x 50 mm and weighing only 142 g. Its 3-pin power input and 7-57 VDC voltage range make it a flexible unmanaged switch tailor-made for industrial use. The TSF010 is equipped with five 10/100 Mbps RJ45 ports for reliable connectivity.
Standard package*
- TSF010
- 3-pin power connector
- QSG (Quick Start Guide)
- Packaging box
*Standard package contents may differ based on standard order codes.
Features
Ethernet Specifications
| Specification |
Details |
| Ethernet Ports |
5 x RJ45 ports, 10/100 Mbps, supports auto MDI/MDIX crossover |
| IEEE 802.3 Series Standards |
802.3i, 802.3u, 802.3ab, 802.3x, 802.3az |
Performance Specifications
| Specification |
Details |
| Bandwidth (Non-blocking) |
10 Gbps |
| Packet Buffer |
128 KB |
| MAC Address Table Size |
2K entries |
| Jumbo Frame Support |
9216 bytes |
Power Specifications
| Specification |
Details |
| Power Connector |
3-pin industrial DC power socket |
| Input Voltage Range |
7 – 57 VDC, overvoltage protection: 60 Vmax, reverse polarity protection: 80 Vmax, surge protection: min 64.4V/max 71.2V breakdown voltage, 93.6V maximum reverse voltage @4.3A maximum reverse surge current |
| Power Consumption |
Idle: 1 W / Max: 1.5 W |
Physical Interfaces
| Specification |
Details |
| Ethernet |
5 x RJ45 ports, 10/100 Mbps |
| Status LEDs |
1 x Power LED, 10 x ETH status LEDs |
| Power |
1 x 3-pin industrial DC power socket |
| Grounding |
Grounding terminal on power connector |
Physical Specification
| Specification |
Details |
| Casing Material |
Anodized aluminum housing and panels |
| Dimensions (W x H x D) |
113 x 28 x 50 mm |
| Weight |
142 g |
| Mounting Options |
Integrated DIN rail bracket |
Operating Environment
| Specification |
Details |
| Operating Temperature |
-40 °C to 75 °C |
| Operating Humidity |
5% to 95% non-condensing |
| Ingress Protection Rating |
IP30 |
