RUTX10 - Professional Ethernet Router
Description
This professional router combines the best of wired and wireless routing functionalities with Gigabit Ethernet, Bluetooth LE, and AC Wi-Fi. Advanced remote management capabilities, along with numerous supported security and networking protocols, make RUTX10 an ideal choice for professional applications
Standard package*
- Router RUTX10
- 18 W PSU
- 2x Wi-Fi antennas (swivel, RP-SMA male)
- 1x Bluetooth antenna (magnetic mount, RP-SMA male, 1.5 m cable)
- Ethernet cable (1.5 m)
- QSG (Quick Start Guide)
- Packaging box
*Standard package contents may differ based on standard order codes.
Features
Ethernet
| Category | Details |
|---|---|
| WAN | 1 x WAN port, 10/100/1000 Mbps, compliant with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover |
| LAN | 3 x LAN ports, 10/100/1000 Mbps, compliant with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover |
Wireless
| Category | Details |
|---|---|
| Wireless Mode | 802.11b/g/n/ac Wave 2 (Wi-Fi 5) with data rates up to 867 Mbps (Dual Band, MU-MIMO), 802.11r fast transition, Access Point (AP), Station (STA) |
| Wi-Fi Security | WPA2-Enterprise: PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE; AES-CCMP, TKIP, Auto-cipher modes, client separation, EAP-TLS with PKCS#12 certificates, 802.11w PMF (Protected Management Frames) |
| SSID/ESSID | ESSID stealth mode |
| Wi-Fi Users | Supports up to 150 simultaneous connections |
| Wireless Connectivity Features | Wireless mesh (802.11s), fast roaming (802.11r), Relayd, BSS transition management (802.11v), radio resource measurement (802.11k) |
| Wireless MAC Filter | Allowlist, blocklist |
| Wireless QR Code Generator | Generates QR codes for automatic Wi-Fi login without manual entry |
| TravelMate | Forwards Wi-Fi hotspot landing page to a subsequent connected device |
Security
| Category | Details |
|---|---|
| SSL Certificate Generation | Supports Let's Encrypt and SCEP certificate generation methods |
| 802.1x | Port-based network access control client |
| Authentication | Pre-shared key, digital certificates, X.509 certificates, TACACS+, Internal & External RADIUS users authentication, IP & login attempts block, time-based login blocking, random password generator |
| Firewall | Preconfigured firewall rules via WebUI, unlimited firewall configuration via CLI, DMZ, NAT, NAT-T, NAT64 |
| Attack Prevention | DDOS prevention (SYN flood, SSH, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks) |
| VLAN | Port and tag-based VLAN separation |
| WEB Filter | Blacklist for blocking unwanted websites, Whitelist for specifying allowed sites |
| Access Control | Flexible access control for SSH, Web interface, CLI, and Telnet |
OPC UA
| Category | Details |
|---|---|
| Supported Modes | Client, Server |
| Supported Connection Types | TCP |
MODBUS
| Category | Details |
|---|---|
| Supported Modes | Server, Client |
| Supported Connection Types | TCP, USB |
| Custom Registers | MODBUS TCP custom register block requests that read/write to a file inside the router. |
| Supported Data Formats | 8-bit: INT, UINT; 16-bit: INT, UINT (MSB or LSB first); 32-bit: float, INT, UINT (ABCD, DCBA, CDAB, BADC), HEX, ASCII |
Data to Server
| Category | Details |
|---|---|
| Protocol | HTTP(S), MQTT, Azure MQTT, Kinesis |
| Data to Server | Extract parameters from multiple sources and protocols and send them to a single server; Custom LUA scripting for utilizing router's Data to Server feature |
MQTT Gateway
| Category | Details |
|---|---|
| Modbus MQTT Gateway | Allows sending commands and receiving data from MODBUS Server through MQTT broker |
DNP3
| Category | Details |
|---|---|
| Supported Modes | Station, Outstation |
| Supported Connection | TCP, USB |
DLMS
| Category | Details |
|---|---|
| DLMS Support | Standard protocol for utility meter data exchange |
| Supported Modes | Client |
| Supported Connection Types | TCP, USB |
COSEM
| Category | Details |
|---|---|
| COSEM Support | Allows scanning meter COSEM objects for automatic detection and configuration |
API
| Category | Details |
|---|---|
| Web API Support | Teltonika Networks Web API (beta) support for configurable API endpoints to retrieve or change data. For more information, refer to Teltonika Networks Web API Documentation |
Monitoring & Management
| Category | Details |
|---|---|
| WEB UI | HTTP/HTTPS, status, configuration, firmware update, CLI, troubleshooting, multiple event log servers, firmware update availability notifications, event log, system log, kernel log, Internet status |
| FOTA | Firmware update from server, automatic notification |
| SSH | SSH (v1, v2) |
| TR-069 | OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem |
| MQTT | MQTT Broker, MQTT publisher |
| SNMP | SNMP (v1, v2, v3), SNMP Trap, Brute force protection |
| JSON-RPC | Management API over HTTP/HTTPS |
| RMS | Teltonika Remote Management System (RMS) |
IoT Platforms
| Platform | Details |
|---|---|
| ThingWorx | Allows monitoring of: WAN Type, WAN IP |
| Cumulocity - Cloud of Things | Allows monitoring of: Device Model, Revision and Serial Number, WAN Type and IP. Includes reboot and firmware upgrade actions |
| Azure IoT Hub | Can be configured with Data to Server to send all parameters to the cloud. Direct method support for RutOS API calls on the IoT Hub. Plug and Play integration with Device Provisioning Service for zero-touch device provisioning. |
System Characteristics
| Category | Details |
|---|---|
| CPU | Quad-core ARM Cortex A7, 717 MHz |
| RAM | 256 MB, DDR3 |
| FLASH Storage | 256 MB, SPI Flash |
Firmware / Configuration
| Category | Details |
|---|---|
| WEB UI | Update FW from file, check FW on server, configuration profiles, configuration backup |
| FOTA | Update FW |
| RMS | Update FW/configuration for multiple devices at once |
| Keep Settings | Update FW without losing current configuration |
| Factory Settings Reset | A full factory reset restores all system settings to default configuration |
| FIRMWARE CUSTOMISATION | OpenWrt based RutOS operating system, supports Busybox shell, Lua, C, C++, Python, Java in Package manager. SDK package with build environment. GPL customization options to modify firmware. |
Location Tracking
| Category | Details |
|---|---|
| NTRIP | NTRIP protocol (Networked Transport of RTCM via Internet Protocol) |
USB
| Category | Details |
|---|---|
| Data Rate | USB 2.0 |
| Applications | Samba share, USB-to-serial |
| External Devices | Possibility to connect external HDD, flash drive, additional modem, printer, USB-serial adapter |
| Storage Formats | FAT, FAT32, exFAT, NTFS (read-only), ext2, ext3, ext4 |
Input / Output
| Category | Details |
|---|---|
| Input | 1 x Digital Input, 0 - 6 V detected as logic low, 8 - 30 V detected as logic high |
| Output | 1 x Digital Output, Open collector output, max output 30 V, 300 mA |
| Events | Email, RMS |
| I/O Juggler | Allows setting certain I/O conditions to initiate event |
Power
| Category | Details |
|---|---|
| Connector | 4-pin industrial DC power socket |
| Input Voltage Range | 9 - 50 VDC, reverse polarity protection, voltage surge/transient protection |
| PoE (Passive) | Power through LAN1 port (not compatible with IEEE802.3af, 802.3at, and 802.3bt standards), Mode B, 9 - 50 VDC |
| Power Consumption | 9 W Max |
Physical Interfaces
| Category | Details |
|---|---|
| Ethernet | 4 x RJ45 ports, 10/100/1000 Mbps |
| I/O’s | 1 x Digital Input, 1 x Digital Output on 4-pin power connector |
| Status LEDs | 8 x LAN status LEDs, 1 x Power LED, 2 x 2.4G and 5G Wi-Fi LEDs |
| Power | 1 x 4-pin power connector |
| Antennas | 2 x RP-SMA for Wi-Fi, 1 x RP-SMA for Bluetooth |
| USB | 1 x USB A port for external devices |
| Reset | Reboot/User default reset/Factory reset button |
| Other | 1 x Grounding screw |
Physical Specification
| Category | Details |
|---|---|
| Casing Material | Aluminium housing |
| Dimensions (W x H x D) | 115 x 32.2 x 95.2 mm |
| Weight | 355 g |
| Mounting Options | DIN rail, wall mount, flat surface (all require additional kit) |
Operating Environment
| Category | Details |
|---|---|
| Operating Temperature | -40 °C to 75 °C |
| Operating Humidity | 10% to 90% non-condensing |
| Ingress Protection Rating | IP30 |
Regulatory & Type Approvals
| Category | Details |
|---|---|
| Regulatory | CE, UKCA, EAC, UCRF, CITC, ICASA, ANRT, FCC, IC, PTCRB, RCM, IMDA, SIRIM, NTC, E-mark, Railway, UL/CSA Safety, CB |
| EMC Emissions & Immunity Standards | EN 55032:2015 + A11:2020, EN 55035:2017 + A11:2020, EN 301 489-1 V2.2.3, EN 301 489-3 V2.1.2, EN 301 489-17 V3.2.4 |
| Radiated Immunity | EN IEC 61000-4-3:2006 + A1:2008 + A2:2010 |
| EFT | EN 61000-4-4:2012 |
| Surge Immunity (AC Mains Power Port) | EN 61000-4-5:2014 + A1:2017 |
| CS | EN 61000-4-6:2014 |
| DIP | EN 61000-4-11:2004 |
| RF Standards | EN 300 328 V2.2.2, EN 301 893 V2.1.1, EN 300 440 V2.2.1 |
| Safety Standards | CE: EN IEC 62368-1:2020 + A11:2020, EN 62311:2020, RCM: AS/NZS 62368.1:2022, CB: IEC 62368-1:2018 |
EMC Emissions & Immunity Standards
| Category | Standard |
|---|---|
| EMC Emissions | EN 55032:2015 + A11:2020 |
| EN 55035:2017 + A11:2020 | |
| EN 301 489-1 V2.2.3 | |
| EN 301 489-3 V2.1.2 | |
| EN 301 489-17 V3.2.4 | |
| Radiated Immunity | EN IEC 61000-4-3:2006 + A1:2008 + A2:2010 |
| EFT (Electrical Fast Transient) | EN 61000-4-4:2012 |
| Surge Immunity (AC Mains Power Port) | EN 61000-4-5:2014 + A1:2017 |
| CS (Conducted Susceptibility) | EN 61000-4-6:2014 |
| DIP (Voltage Dips and Interruptions) | EN 61000-4-11:2004 |
RF Standards
| Category | Standard |
|---|---|
| RF Standards | EN 300 328 V2.2.2 |
| EN 301 893 V2.1.1 | |
| EN 300 440 V2.2.1 |
Safety Standards
| Category | Standard |
|---|---|
| Safety Standards (CE) | EN IEC 62368-1:2020 + A11:2020, EN 62311:2020 |
| Safety Standards (RCM) | AS/NZS 62368.1:2022 |
| Safety Standards (CB) | IEC 62368-1:2018 |
