Orbbec GEMINI 336L
Gemini 336L is a new member of Orbbec's Gemini 330 series.
Building on the exceptional depth performance and quality of the Gemini 335L, the Gemini 336L enhances active infrared imaging by filtering visible light. This optimization significantly improves depth quality in scenarios including strong outdoor lighting, indoor reflections, and shadowed areas within high dynamic range scenes with sunlight exposure.
These enhancements ensure stable, high-quality depth data for users across various challenging lighting conditions.
- Stable Infrared Imaging
- Further and Precise
- IP65 Rated
Technical Specs
| Product Name |
Gemini 336L |
|---|---|
| Model |
G40155-180 |
| Depth Technology |
Stereo |
| Depth Range |
*0.10 - 10m (Optimal Range: 0.5 - 6m) |
| Depth Resolution/FPS |
Up to 1280X800@30fps |
| Depth FOV |
H90° V65° |
| RGB Resolution/FPS |
Up to 1280X800@60fps |
| RGB FOV |
H94° V68° |
| Processing |
Orbbec ASIC |
| Depth Filter |
IR-Pass |
| IMU |
Supported |
| Data Connection |
USB 3.0 Type-C |
| Power Input |
USB 3.0 Type-C |
| Trigger |
Supported |
| Power Consumption |
Average < 2.5W |
| Operating Environment |
-10℃ - 50℃; Indoor/Outdoor; 5%~95%RH (non-condensing) |
| SDK Support |
Orbbec SDK |
| Data Output |
Point Cloud, Depth Map, IR & RGB |
|
Dimensions (W*H*D) |
124mm x 29mm x 27.7mm |
| Weight |
135g |
| Installation |
Bottom: ¼-20UNC |
| Wavelength |
850nm |
Description
Gemini 336L is a new member of Orbbec's Gemini 330 series.
Building on the exceptional depth performance and quality of the Gemini 335L, the Gemini 336L enhances active infrared imaging by filtering visible light. This optimization significantly improves depth quality in scenarios including strong outdoor lighting, indoor reflections, and shadowed areas within high dynamic range scenes with sunlight exposure.
These enhancements ensure stable, high-quality depth data for users across various challenging lighting conditions.
- Stable Infrared Imaging
- Further and Precise
- IP65 Rated
Technical Specs
| Product Name |
Gemini 336L |
|---|---|
| Model |
G40155-180 |
| Depth Technology |
Stereo |
| Depth Range |
*0.10 - 10m (Optimal Range: 0.5 - 6m) |
| Depth Resolution/FPS |
Up to 1280X800@30fps |
| Depth FOV |
H90° V65° |
| RGB Resolution/FPS |
Up to 1280X800@60fps |
| RGB FOV |
H94° V68° |
| Processing |
Orbbec ASIC |
| Depth Filter |
IR-Pass |
| IMU |
Supported |
| Data Connection |
USB 3.0 Type-C |
| Power Input |
USB 3.0 Type-C |
| Trigger |
Supported |
| Power Consumption |
Average < 2.5W |
| Operating Environment |
-10℃ - 50℃; Indoor/Outdoor; 5%~95%RH (non-condensing) |
| SDK Support |
Orbbec SDK |
| Data Output |
Point Cloud, Depth Map, IR & RGB |
|
Dimensions (W*H*D) |
124mm x 29mm x 27.7mm |
| Weight |
135g |
| Installation |
Bottom: ¼-20UNC |
| Wavelength |
850nm |
