IMX378-190 Fisheye Lens 12.3MP Camera for Raspberry Pi - Wider Field Of View
IMX378-190 Fisheye Lens Camera
12.3MP, Fisheye, 190°FOV
Compatible with Raspberry Pi series boards
Device Support
Raspberry Pi series
Supports 4B / 3B+ / 3A+ / Zero / Zero 2 W,
and CM3/3+/4 (extra adapter board required)
Specifications
| SENSOR | IMX378 | CMOS SIZE | 1/2.3 inch |
|---|---|---|---|
| CAMERA TYPE | color | PIXELS | 12.3MP (4056 × 3040) |
| SHUTTER | Rolling Shutter | APERTURE | F2.4 |
| DISTORTION | < 58% | FIELD OF VIEW | 190° |
| FOCAL LENGTH | 6.5mm | FOCUSING | fixed focus distance |
High Definition, Wide Angle
12.3MP HD, More Clear Imaging
190° Wide Angle Fisheye Lens, Cover All In Sight
Working With Raspberry Pi
Direct Connect To Raspberry Pi Different Variants Including 4B/3B+/3A+/3B/2B/B+/A+,
Extra FPC Cable Is Required For Zero / Zero 2 W Series
* for reference only, Raspberry Pi and yellow FPC are NOT included.
Dimensions
Resources
Wiki: IMX378-190_12.3MP_Camera$16.19
Original: $53.97
-70%IMX378-190 Fisheye Lens 12.3MP Camera for Raspberry Pi - Wider Field Of View—
$53.97
$16.19
Description
IMX378-190 Fisheye Lens Camera
12.3MP, Fisheye, 190°FOV
Compatible with Raspberry Pi series boards
Device Support
Raspberry Pi series
Supports 4B / 3B+ / 3A+ / Zero / Zero 2 W,
and CM3/3+/4 (extra adapter board required)
Specifications
| SENSOR | IMX378 | CMOS SIZE | 1/2.3 inch |
|---|---|---|---|
| CAMERA TYPE | color | PIXELS | 12.3MP (4056 × 3040) |
| SHUTTER | Rolling Shutter | APERTURE | F2.4 |
| DISTORTION | < 58% | FIELD OF VIEW | 190° |
| FOCAL LENGTH | 6.5mm | FOCUSING | fixed focus distance |
High Definition, Wide Angle
12.3MP HD, More Clear Imaging
190° Wide Angle Fisheye Lens, Cover All In Sight
Working With Raspberry Pi
Direct Connect To Raspberry Pi Different Variants Including 4B/3B+/3A+/3B/2B/B+/A+,
Extra FPC Cable Is Required For Zero / Zero 2 W Series
* for reference only, Raspberry Pi and yellow FPC are NOT included.
Dimensions
