Waveshare 1.3 inch OLED with Vertical Pin header
1.3inch OLED, SPI/I2C Interfaces, Straight/Vertical Pin header
The OLED module provides three drive interfaces: 3-wire SPI, 4-wire SPI, and I2C interface respectively. There are two resistors that can be soldered on the back of the module
Features:
- Driver Chip: SH1106
- Interface: 3-wire SPI, 4-wire SPI, I2C
- Resolution: 128X64
- Display Size: 1.3inch
- Colors: Blue
- Visible Angle >160°
- Operating Temperature (℃): -30~70
- Storage Temperature (℃): -30~80
- Operating Voltage: 3.3V / 5V
- Applicability: Hardware platforms such as Raspberry Pi/Jetson Nano/Arduino/STM32
Interface
- VCC - 3.3V / 5V power input
- GND - Ground
- NC: No Connection
- DIN - Data Input / SPI MOSI pin
- CLK - Clock / SPI SCK pin
- CS - SPI chip selection, low active
- DC - Data/Command selection (high for data, low for command)
- RST - External reset, low active
