OAK-D-POE OpenCV AI Machine Vision Kit

OAK-D-POE OpenCV AI Machine Vision Kit

OAK-D-POE Development Kit With PoE Feature, OpenCV AI Machine Vision Kit, IP67 Waterproof

Depth Measuring / Image Recognition / Security Monitoring / Ntelligent Driving / Robotics / Gigabit Ethernet PoE / IP67 Waterproof


Specifications

DEPTH MEASURING RANGE 0.2 ~ 9 m
DEPTH CAMERA global shutter
RGB CAMERA 12MP
MAX FRAMERATE 60fps (RGB), 200fps (Depth)
AI CHIP Intel Myriad X 4TOPS computing performance
VIDEO PLUG FLOW 4K 30 fps H.265 plug flow
CONNECTOR Gigabit Ethernet, with 802.3af-compliant PoE circuit
EXPANSION INTERFACES GPIO, SPI, UART
NN PLATFORM SUPPORT all platforms
POWER CONSUMPTION 2W ~ 5.5W
DEVELOPMENT LANGUAGE Python, C++
ECLOSURE aluminum enclosure
WEIGHT 361g

Powerful Computing Performance

The OAK Provides Up To 4TOPS Computing Performance,
10 Times Of OpenMV, 40 Times Of Raspberry Pi 4B


Camera Specifications


IP67 Waterproof


Use Free Neural Networks
Or Create Your Own

The OAK adopts Myriad X for binocular depth calculating as well as AI neural inference, then providing direct outputs like target coordinates, IMU data, recognition results, and so on. More other functions can be achieved by calling the API, which allows you to build your own system easier.



Extensive Applications

The OAK Can Be Widely Used Thanks To Its Rich Functions And Technologies, It Will Upgrade Your Project To The Next Level By Enabling The Computer Vision Feature

Intelligent traffic
Detection and recognition for motor vehicles, non-motor vehicles, pedestrians, traffic signs, traffic events...

Intelligent driving
Recognizing and ranging around vehicles and road conditions, recognizing the driver status and providing intelligent assistance.

Intelligent safety & security
The neural network keeps learning new sudden human body features and event accidents, providing intelligent detection and giving alarm for human abnormal behaviors and accidents.

Robotics
Used on industrial robots field, enabling robot functions like target identification, positioning, size measuring, binocular depth mapping, navigation...

Math contest
Suitable for teaching competitions like robotic vision, OpenCV, AI IoT projects, Python programming, and so on.

Platform & Language Support

Framework & Neural Network Support


Working With Tripod

**for reference only, the Mini Tripod is NOT included.

Outline Dimensions

Resources & Services

Wiki: OAK-D-POE
