JCG604LM4 LTE MIMO×4 Combination Antenna

The JCE604LMWM4 from JC Antenna is an advanced 4-in-1 combination antenna engineered for high-performance wireless communication. Integrating 4x LTE MIMO in one low-profile enclosure, this antenna is ideal for data-intensive applications.

Designed for automotive, smart city, and industrial IoT environments, the JCE604LMWM4 ensures robust connectivity even in challenging conditions. Its rugged, weatherproof housing supports outdoor installations, while multiple cable and connector options enable seamless integration into existing systems.

Whether deployed on vehicles, kiosks, or industrial equipment, the JCE604LMWM4 offers the reliable, high-speed connectivity needed for modern connected systems.

Specifications:

Item		Specifications
LTE Antenna MIMO*4	Frequency Range	698~960MHz/1710~2690MHz
	V.S.W.R	＜3.0
	Polarization	Linear
	Gain	3dBi
	Impedance	50Ω
Mechanical	Cable	RG174
	Connector	SMA or others
	Radome Material	ABS
	Mounting Method	Screw
Environmental	Operating Temperature	-40℃
	Relative Humidity	Up to 95%
	Ingress Protection	IP67 (exclude cable outlet)
	Vibration	10 to 55Hz with 1.5mm amplitude 2hours
	Environmentally Friendly	ROHS Compliant
