SIM8200-M2 SIMCom Original 5G Module
IM8200-M2 SIMCom Original 5G Module
M.2 Form Factor, High Throughput Data Communication
The SIM8200-M2 series is the Multi-Band 5G NR/LTE-FDD/LTE-TDD/HSPA+ module which supports R15 5G NSA/SA up to 2.4Gbps data transfer.
It has strong extension capability with rich interfaces including UART,PCIe,USB3.1, GPIO etc. The module provides much flexibility and ease of integration for customer's application.
The SIM8200-M2 series adopts M.2 form factor, TYPE 3052-S3-B. AT commands of SIM8200-M2 series are compatible with SIM7912G/SIM8300G-M2 series modules. This also minimizes the investments of customers, and enables a short time-to-market.
It is designed for applications that need high throughput data communication in a variety of radio propagation conditions. Due to the unique combination of performance, security and flexibility, this module is ideally suited for many applications.
Product Advantages
- Standard M.2 interface.
- High throughput data communication.
- AT commands of the SIM8200-M2 series are compatible with SIM7912G/SIM8300G-M2 series modules
Wiki: SIM8200EA-M2_5G_HAT
Specifications
| PRODUCT | SIM8200EA-M2 |
|---|---|
| FREQUENCY BAND | |
| Sub-6G (SA) | n1, n2, n3, n5, n7, n8, n12, n20, n28, n38, n40, n41, n48, n66, n71, n77, n78 |
| Sub-6G (NSA) | n41, n77, n78 |
| LTE-FDD | B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B66, B71 |
| LTE-TDD | B34, B38, B39, B40, B41, B42, B43, B48 |
| WCDMA | B1, B2, B3, B4, B5, B8 |
| GNSS | GPS, GLONASS, Beidou, Galileo, and QZSS |
| DATA RATE | |
| Sub-6G | 2.4 Gbps (DL) / 500 Mbps (UL) |
| LTE | 1 Gbps (DL) / 200 Mbps (UL) |
| HSPA | 42 Mbps (DL) / 5.76 Mbps (UL) |
| SOFTWARE FUNCTIONS | |
| Operating systems | Windows/Linux/Android |
| Communication protocols | TCP/IP, IPV4, IPV6, Multi-PDP, FTP, FTPS, HTTP, HTTPS, MQTTS, DNS, SSL3.0 |
| SMS | Supports MT, MO, CB, Text, PDU |
| Firmware upgrade | Supports firmware upgrade via USB port |
| HARDWARE INFO | |
| SIM card | 1.8V/3.0V |
| Antenna connector | 6x IPEX-4 connector, for 3G/4G/5G/GNSS |
| Power supply | 5V 3A |
| Form factor | M.2 |
| Dimensions | 52.0 × 30.0 × 2.3mm |
| Operating temperature | -30℃ ~ +70℃ |
| APPLICATIONS | |
| Applicable regions | China, US, Japan, South Korea, Europe, the Middle East, Latin America, etc. |
| Application examples | CPE, Smart gateway, Drone, Live streaming, Remote medical treatment, Intelligent security |
Original: $292.62
-70%$292.62
$87.79
