Radxa Palmshell SLiM X4L

Palmshell SLiM X4L

A Feature-Packed, Stylishly Pocket PC

Palmshell SLiM X4L is a pocket-sized mini-PC, featuring a quad-core Intel CPU, dual 4K HDMI outputs, and a 2.5 Gigabit Ethernet port. It's perfect for presentations, speeches, office work, and travel.





Put Productivity Tools in Your Pocket

Feature-Rich Functionality, Compact Design

CPU	Intel® Processor N100 4 Cores / 4 Threads Max Turbo Frequency: 3.40 GHz Intel’s mobile PC processor helps users collaborate, create, learn, and play like never before. It powers thin and light PCs with the security and connectivity for a modern lifestyle.
Graphics	Intel® UHD Graphics Burst Frequency: 750 MHz Execution Units: 24 DirectX Support: 12.1 OpenGL Support: 4.6 OpenCL Support: 3.0
Memory	Up to 32 GB RAM Memory Type: LPDDR5 @ 4800 MT/s With up to 32GB of LPDDR5@4800MT/s RAM, experience blazing-fast responsiveness and seamless multitasking for an unparalleled computing experience.
Storage	M.2 M Key for NVMe SSD Supercharge your storage with M.2 M Key support for NVMe SSD. Enjoy lightning-fast data transfer and enhanced performance.
Ethernet	2.5 Gigabit RJ45 Port Experience blazing-fast 2.5 Gigabit Ethernet for seamless streaming, quick downloads, and lag-free gaming.
Wi-Fi / Bluetooth	Built-in Wi-Fi 6 / BT 5.2 Module Supports IEEE 802.11a/b/g/n/ac/ax and Bluetooth 5.2





Software

Supports Multiple OS

Supports almost all operating systems compatible with the X86 architecture.

Equipped with an intelligent temperature-controlled variable speed fan, coupled with a unique heat dissipation airflow design, our system ensures optimal performance while maintaining a low noise level, even under heavy workloads





Applications

Compact and portable, supports dual-screen output and Wi-Fi 6, take your pocket PC with you anytime, anywhere.





So small, but great at cooling

Equipped with a 7000RPM PWM speed-controlled fan, balancing cooling and quiet operation.





Small and Handy





Intel® Processor N100

4 Cores | 4 Threads | Base Freq: 2.0GHz | Burst Freq: 3.4GHz

Perfect for office tasks.

Quad-core, Fearless Multitasking

TDP: 6W | Cache: 6 MB





Efficient office power powered by Intel® UHD Graphics



Boosting Productivity

Up to 32GB LPDDR5@4800MT/s





Experience Smooth and Fast Networking with 2.5 Gigabit Ethernet





Supports Higher Quality
Wireless Networks





Optional VESA Mount Support







M.2 M Key for NVMe SSD

Supercharge your storage with M.2 M Key support for NVMe SSD. Enjoy lightning-fast
data transfer and enhanced performance.





Applications

Office



Fits Right in Your Pocket



Easy to Take Anywhere





Supports Multiple OS





Specification

Model	8 + 256	16 + 512	32 + 1024
CPU	Intel N100, Quad-Core up to 3.4GHz
Memory (LPDDR5 @ 4800 MT/s)	8GB	16GB	32GB
Ethernet	1 x 2.5 Gigabit RJ45 port
Wireless	AW-XB547NF (Wi-Fi 6 / BT 5.2) with 2x antennas
Display	2x HDMI 2.0 up to dual 4Kp60 support
USB	3x USB 3 + 1x USB 2
Storage	256GB NVMe SSD	512GB NVMe SSD	1024GB NVMe SSD
Audio	1x 3.5mm jack, support audio input/output
Power Supply	Not included, 12V/3A direct or USB PD (Power Delivery) capable power adapter with USB C connector required
Others	1x Power Button 1x R (Recovery) Button 1x Status LED 1x Kensington Lock
Enclosure	Yes
Mount	Optional VESA mount brackets





Download

Drivers & Tools

Name	Version	Description
N100_DRV_Chipset_Intel_TP_W11_64.zip	10.1.19222.8341	Chipset Driver for Intel N100
intel_gfx_win_31_0_101_4577.zip	31.0.101.4577	Graphic Driver for Intel N100
ME_heci.inf_amd64_6467379f0b0f181f.zip	2229.3.2.0	Intel® Management Engine Drivers
SIO_ialpss2_gpio2_adl_n.inf_amd64_cacc621ea12c00b5.zip	30.100.2229.4	INTEL GPIO Drivers
SIO_ialpss2_i2c_adl_n.inf_amd64_cea888afe7e27a33.zip	30.100.2229.4	INTEL I2C Drivers
INTEL_LAN_Release_29.1.2.zip	1.1.4.43	INTEL 225/226 Ethernet Drivers
RTLAudio_Win10_R282.exe	6.0.1.8186	Realtek ALC269 Audio Drivers
zadig-2.8.exe	2.8	RP2040 Drivers
wireless_module_a8.zip	6001.15.117.0	Radxa_A8_Wireless_BT_module Drivers
AX210_BT-22.200.0-64UWD-Win10-Win11.exe	22.200.0	BT Driver for AX210 Wireless module Second source for X4L
AX210_WiFi-22.200.2-Driver64-Win10-Win11.exe	22.200.2	WIFI Driver for AX210 Wireless module Second source for X4L



BIOS & Firmware

Name	Version	Description
X4L_v009.zip	20240630	BIOS for SLiM X4L Usage: unzip the EFI folder to FAT32 USB disk, insert USB disk into X4L and boot from USB devices, automatic flash the BIOS. WARNING: Don't turn off your computer During BIOS upgrade



User Manual

User Manual

Download
