10.4inch QLED Display
10.4″ QLED Touch Display
High Resolution | Multi-Point Touch | Full Color
Size 10.4"
|
Resolution 1600×720
|
Display Port HDMI
|
Display Panel QLED Quantum Dot
|
Viewing Angle 170°
|
Touch Type Capacitive
|
Touch Points 10-Point
|
Touch Type USB Type-C |
Touch Panel Toughened Glass
|
Touch Panel Tech Optical Bonding
|
Brightness Supports DCC/CI |
OSD Menu Brightness/Contrast
|
Audio Output1 3.5mm Jack
|
Audio Output2 4PIN Header
|
Brightness 600cd/m²
|
Device System Support
 |
Raspberry Pi Supports Raspbian, 10-points touch, driver free
Supports Ubuntu / Kali / WIN10 IoT, single point touch, driver free Supports Retropie, driver free Supports all versions of Raspberry Pi Jetson Nano
Supports Ubuntu, single point touch, driver free
PC
Supports Windows 11 / 10 / 8.1 / 8 / 7, 10-points touch, driver free
Game Console
Xbox360, PS4, Switch...
|
Connection Examples
Working With Raspberry Pi 4B
Working With Raspberry Pi 3B+
Working With Raspberry Pi Zero 2 W
You need to prepare additional mini HDMI adapter and USB cable
Working With Jetson Nano
Working With PC
IPS Display Panel
Excellent Display Performance With 178° Wide Viewing Angle
QLED Quantum Dot Technology
Wider Color Gamut
Color Gamut Of This QLED Display Is Up To: SRGB 94%, NTSC 94%
More Pure Chroma
Chroma Of QLED Increases 58.3%, Makes The Color More Pure, More Vivid
Longer Lifetime
Due To Its Inorganic Characteristic, The Color Life Of QLED Could Be Up To 60000 Hours Without Color Degradation
Capacitive 10-Point Touch
- up to 10-point touch, depending on the operating system
- up to 6H hardness toughened glass panel
- Optical Bonding, display well and dustproof
Supports DDC/CI Brightness Adjustment
Interface Introduction
Dimensions
Resources
Wiki: www.waveshare.com/wiki/10.4HP-CAPQLED
Package Contains:
Weight: 0.769 kg
- 10.4HP-CAPQLED ×1
- HDMI flat cable ~1m ×1
- USB-A to USB-C cable ~1m ×1
- Button board ×1
- Button board cable ×1
- USB to Type-C adapter (B) ×1
- USB to Type-C adapter (C) ×1
- HDMI to Micro HDMI adapter ×1
- HDMI adapter ×1
- Screws pack ×1
- OPTIONS 5V 3A Type C Power supply ×1
