Pulse ESC P80 5-14S 80A
XOAR Pulse ESC - part of the family of XOAR Propulsion System.
Features
- Fast Response
- High Efficiency
- Low Noise
- Temperature and Interference
- Optimized to work with XOAR Titan T8110, T8115, T8120, Titan Air TA8010, TA8015, TA8020, TA8025, TA8220, TA8225.
Specifications
| Model | 80A |
| BEC | NA |
| PWM Voltage | 3.3V/5V(compatible) |
| Online Update | NA |
| Accelerator Protection | included |
| Short -circuit Protection | included |
| Size(L*W*H) | 79.6*36*23.5mm |
| Power Line | 12AWG |
| Lithium Battery | 5-14s |
| Recommended Battery | 12s |
| Compatible Signal Frequency | 50-500Hz |
| Current Protection | included |
| Stalling Protection | included |
| Error Signal Output | included |
| Protection Grade | IP67（sealing） |
| Motor Line | 14AWG |
| Continuous Current | 80A(good cooling condition) |
| Instant Current | 120A（good cooling condition） |
| Accelerator Pulse Width | default 1050us-1940us,support accelerator adjustment |
| Voltage Protection | included |
| Temperature Protection | included |
| Speed Signal Output | included |
| Weight(without lines) | ≈90g |
| Working Temperature | -20~65℃ |
$33.34
Original: $111.12
-70%Pulse ESC P80 5-14S 80A—
$111.12
$33.34
Description
XOAR Pulse ESC - part of the family of XOAR Propulsion System.
Features
- Fast Response
- High Efficiency
- Low Noise
- Temperature and Interference
- Optimized to work with XOAR Titan T8110, T8115, T8120, Titan Air TA8010, TA8015, TA8020, TA8025, TA8220, TA8225.
Specifications
| Model | 80A |
| BEC | NA |
| PWM Voltage | 3.3V/5V(compatible) |
| Online Update | NA |
| Accelerator Protection | included |
| Short -circuit Protection | included |
| Size(L*W*H) | 79.6*36*23.5mm |
| Power Line | 12AWG |
| Lithium Battery | 5-14s |
| Recommended Battery | 12s |
| Compatible Signal Frequency | 50-500Hz |
| Current Protection | included |
| Stalling Protection | included |
| Error Signal Output | included |
| Protection Grade | IP67（sealing） |
| Motor Line | 14AWG |
| Continuous Current | 80A(good cooling condition) |
| Instant Current | 120A（good cooling condition） |
| Accelerator Pulse Width | default 1050us-1940us,support accelerator adjustment |
| Voltage Protection | included |
| Temperature Protection | included |
| Speed Signal Output | included |
| Weight(without lines) | ≈90g |
| Working Temperature | -20~65℃ |
