High Resolution 1500TVL FPV Camera 2.1mm Lens 1/3" SUPER HAD II CCD with integrated OSD For RC FPV Racing Drone

This 1500TVL CMOS Camera can be used as both PAL and NTSC. The toggle switch is provided on the camera for switching between PAL and NTSC.

This camera is very compact and easy to use. This camera is tailored for FPV which offers delicate clear image, micro ultralight design, high definition color.

Specifications:

• Image Sensor: 1/3" Mg SUPER HAD II CCD
• Horizontal Resolution: 1500TVL
• Lens: 2.1mm
• S/N Ratio: >600dB (AGC Off)
• Electronic Shutter Speed: 1/50 ~ 100,000 (PAL), 1/60 ~ 100,000 (NTSC)
• Autogain Control (AGC): Low/Middle/High
• Backlight Compensation: Yes
• Min. Illumination: 0.001 Lux / 1.2F
• WDR: D-WDR
• DNR: 3DNR
• Day/Night: Color/Auto/B&W
• Power: 5- 30V
• Net Weight: 15 grams
• Dimensions: 22.0mm X 25.0mm X 28.00mm

OSD Adjustments:

• Exposure Brightness / exposure mode / gain
• White Balance: Automatic tracking white balance
• Day & Night Mode: Internal Automatic / Color Mode / B&W Mode
• Video Settings: Contrast / Sharpness / Saturation / Digital Noise / Video Format (NTSC/PAL)
• Language: Chinese/ English / Russian / Italian / German
