DC to DC Step Up 5V Boost Converter

Fixed 5V Output Boost Regulator (step-up regulator) Module with standard USB Connector. Accepts Input voltage from 0.9V to upto 5V. Ideal for powering 5V USB devices from lower voltage batteries like 16340 or AA batteries.

Description:

• On-board CE8301 Chip

• Input voltage: 0.9V-5V DC

• PFM Control DC-DC Converter

• Transfer efficiency: 96%(max)

• With USB port

• With working indicator light

• with one AA battery power supply output current can be up to 200~300mA,

• two AA batteries to the output current of 500~600mA

• On board LED indicator that indicates if Load is connected.



Specifications

Tutorial
