Dual USB 5V 1A 2.1A 18650 Battery Charger Module with LCD Display
Dual USB Charging Control Board for mobile power banks. The LCD Display module provides charge status. The module provides overload protection, over-discharge protection and overcurrent protection.
Specification:
- Micro USB input: 5 V 1A
- USB output: 5V 2.1A / 5V 1A (Dual USB interface)
- Charging screen: intelligent digital screen
- Type of batteries: liquid lithium ion batteries (18650)
- Product size: 57mm x 28mm
- Screen size: 27mm x 17mm
- Input Voltage: 3.7V
Installation instructions:
- The circuit board is connected to the negative battery B-, B is positive
- Check polarity, wrong wiring will burn the board.
- the battery is connected in parallel welding.
- There is insulation between the battery and the circuit board
- The battery can not touch the circuit board, may cause short circuit if it does.
Specifications
Resources
Datasheet
Tutorial
$0.89
Original: $2.96
-70%Dual USB 5V 1A 2.1A 18650 Battery Charger Module with LCD Display—
$2.96
$0.89
Description
Dual USB Charging Control Board for mobile power banks. The LCD Display module provides charge status. The module provides overload protection, over-discharge protection and overcurrent protection.
Specification:
- Micro USB input: 5 V 1A
- USB output: 5V 2.1A / 5V 1A (Dual USB interface)
- Charging screen: intelligent digital screen
- Type of batteries: liquid lithium ion batteries (18650)
- Product size: 57mm x 28mm
- Screen size: 27mm x 17mm
- Input Voltage: 3.7V
Installation instructions:
- The circuit board is connected to the negative battery B-, B is positive
- Check polarity, wrong wiring will burn the board.
- the battery is connected in parallel welding.
- There is insulation between the battery and the circuit board
- The battery can not touch the circuit board, may cause short circuit if it does.
